All-In-One Machine Helmet-integrated Smart VR Glasses

MG01 helmet-integrated smart VR glasses deliver an immersive experience and support various applications, including entertainment, live TV, and video conferencing.

  • MG01

  • > 120g

  • No

  • High-Definition display

  • Yes

  • 2-4 hours

  • Yes

  • No

  • Wireless

  • Supported (Custom/Adjustable)

Availability:
Quantity:
Inquire Add to Basket

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
snapchat sharing button
telegram sharing button
sharethis sharing button

This VR smart glasses are an all-in-one device designed for users who seek an immersive experience. It combines virtual reality gaming, movie watching, and social interaction features, providing users with an unparalleled entertainment experience. The glasses have a modern and stylish design, ensuring comfortable wear, while the high-definition display delivers vivid visuals that make users feel as though they are in a virtual world.


It supports a high adjustable angle ranging from -15° to 75°, accommodating various viewing preferences. The ultra-high-definition display technology ensures that every detail is crystal clear, offering an engaging visual experience. The built-in stereo speakers provide high-fidelity sound, enhancing immersion and allowing you to experience realistic audio in the virtual realm.


The electric refractive adjustment feature enables users with different vision levels to enjoy the device easily, supporting multi-user functionality for family and friends to share the fun. Additionally, the user-friendly multiple adjustment modes allow users to easily tailor settings to their preferences.Seamless Battery Replacement: This feature utilizes a high-capacity 18650 battery, allowing for hot-swapping without the need to power down the device.

All-In-One Machine VR Glasses -MG01 VR Glasses 1All-In-One Machine VR Glasses -MG01 VR Glasses 2All-In-One Machine VR Glasses -MG01 VR Glasses 3All-In-One Machine VR Glasses -MG01 VR Glasses 4All-In-One Machine VR Glasses -MG01 VR Glasses 5All-In-One Machine VR Glasses -MG01 VR Glasses 6


1. Ultralight and Portable Design :

  • Ultra-thin 16.5mm lens body.

  • Lightweight at only 265g.


2. Automated Diopter Adjustment :

  • Precise electronic adjustment of diopter settings.

  • Diopter preferences can be saved and recalled.


3. Uninterrupted Battery Swapping :

  • High-capacity 18650 battery.

  • Allows hot-swapping batteries without powering off.


4. Cinematic 4K Visual Experience :

  • Massive 200-inch screen at 5 meters.

  • 1920 x 1200 ultra-high definition resolution.

  • 60Hz refresh rate for smooth motion.

  • Excellent contrast and wide color gamut.


5. Immersive Spatial Audio :

  • Dual SmartPA stereo speakers.


6. Versatile Connectivity Options :

  • 3.5mm headphone jack.

  • USB-C port.

  • Built-in microphone for recording.


7. Plug-and-Play Usability :

  • Instant-on with integrated battery.

  • Seamless Wi-Fi and Bluetooth connectivity.

  • Supports IMU sensors.

  • Wear detection for automatic enablement.


8. Wireless Casting Capabilities :

  • Supports Miracast, DLNA, AirPlay, and Mbox.


This device combines an ultralight, portable design with a cinematic visual experience, immersive audio, and flexible connectivity - making it well-suited for entertainment, remote work, and on-the-go use.


ATTRIBUTE CONTENT
 DETAILED
Main Config Platform RK3566
CPU Quad-Core Cortex-A55
GPU Mali-G52 1-Core-2EE
RAM 2GB LPDDR4
ROM 32GB eMMC5.1
OS Android 11
Display Type Seeya Si-OLED
Size 0.72" (1920×1200)
Quantity *2
Aspect ratio 16:10
Resolution 1920*1200*2 RGB
Interface MIPI
Luminance uniformity >85%
Framerate 60Hz
Optical Solution Lensgroup type
Diopter Range 2D ~ -8D
IPD 60~72mm
FOV 55° (0D)
FOV Tolerance <2°
Luminace to eyes 400nits @ Center
Chrmatic MTF 0F:>0.9@30lp/mm; 1.0F>0.5@30lp.mm
Eyebox 8mm*6mm
Eyerelief >12mm
Diopter Tolerance ≤0.25D
TV distortion <3%
Luminace efficincy 80%
Virtual image distance 3~5m
Audio Type Speaker
Quantity *2
Power 1W
SPL 87 dB (0.1W/0.1m)
THD <5% (200-8000Hz)
FR F0< 350Hz
EQ Smart PA
Microphone Quantity *2
SN 60dB (1KHz S.P.L = 1Pa)
Keys Power key yes
Function key hot key * 2
Sensors Acceleration Yes
Gyroscope Yes
Geomagnetism Yes
Psensor Yes
I/O Type-C USB 3.0 Yes, *1
TF card Yes, *1
LED RGB led Yes
Net BT&BLE Yes
WIFI5 2.4/5GHz, 802.11 a/b/g/n/ac, 2×2 MIMO
Miracast Yes
DLNA&Airplay Yes
Android Cast Yes
Multimedia Video Container MPEG 1/2/4, Sorenson H.263,H.264, HEVC /H.265
AVS, AVS+, Motion JPEG, VP8, VP9, RV30, RV40
Audio Container MPEG 1/2 AC3, EAC3, VORBIS, DTS, LPCM, LBR(cook)
FLAC, DRA, DTS LBR, DTS XLL, AAC
Photo JPEG, PNG, BMP
Power Battery Yes
Capacity 3000mAh (removeable)
Charge Parameters 5V-2.1A
Working time 3 Hours
Power Consumption <3W
Dimension Size W 151.5 * H 55.5 * T 16.5 mm
Weight 300g
